TAPstack TAPs

Network TAPs Products

TAPstack Series -

Cost-Effective Family of TAP to improve network visibility in less space

The TAPstack Series

  • The TAPstack Series is a family of Passive and Secure Fiber Optic TAPs, designed to enable rapid, effective access to live traffic traversing high-speed optical fibre networks links for network monitoring, analysis and cyber-security applications.
  • TAPstack provides network operators with the ability to rapidly and effectively deploy analysis tools to observe and monitor high-speed optical networks.

  • TAPstack is a slim rack-mounted device that supports up to 24 ports in a single rack unit. Models are available to support both duplex and parallel optical links, for multimode (MMF) and singlemode fiber (SMF), and rates right up to 100 Gb/s.





TAPstack TAPs for LC Duplex links (other splits ratios available 10/90, 20/80, 40/60)
EN-TPSTCK2L25G-M55 TAPstack device with Two Links Passive fiber TAP supports Multimode 1G/10G/25G SR, Split ratio of  50/50, Slim 1/3U of 19" Rack height
EN-TPSTCK4L25G-M55 TAPstack device with Four Links Passive fiber TAP supports Multimode 1G/10G/25G SR, Split ratio of  50/50, Slim 1/3U of 19" Rack height
EN-TPSTCK8L25G-M55 TAPstack device with Eight (8) Links Passive fiber TAPs supports Multimode 1G/10G/25G SR, Split ratio of  50/50, Slim 1/3U of 19" Rack height
EN-TPSTCK2L25G-M73 TAPstack device with Two Links Passive fiber TAP supports Multimode 1G/10G/25G SR, Split ratio of  70/30, Slim 1/3U of 19" Rack height
EN-TPSTCK4L25G-M73 TAPstack device with Four Links Passive fiber TAP supports Multimode 1G/10G/25G SR, Split ratio of  70/30, Slim 1/3U of 19" Rack height
EN-TPSTCK8L25G-M73 TAPstack device with Eight (8) Links Passive fiber TAPs supports Multimode 1G/10G/25G SR, Split ratio of  70/30, Slim 1/3U of 19" Rack height
EN-TPSTCK2L100G-S73 TAPstack device with Two Links Passive fiber TAPs supports singlemode 1G/10G/25G/40G/50G/100G LR, Split ratio of 70/30, Slim 1/3U of 19" Rack height
EN-TPSTCK4L100G-S73 TAPstack device with Four Links Passive fiber TAP supports singlemode 1G/10G/25G/40G/50G/100G LR, Split ratio of 70/30, Slim 1/3U of 19" Rack height
EN-TPSTCK8L100G-S73 TAPstack device with Eight (8) Links Passive fiber TAPs supports singlemode 1G/10G/25G/40G/50G/100G LR, Split ratio of 70/30, Slim 1/3U of 19" Rack height
TAPstack TAPs for MPO/MTP PARALLEL (8-FIBER/20-FIBER) (other splits ratios available 10/90, 20/80, 40/60)
EN-TPSTCK1L100G-M55 TAPstack device with One Link Passive fiber TAP supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 50/50, Slim 1/3U of 19" Rack height, Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK2L100G-M55 TAPstack device with TWO Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 50/50, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK4L100G-M55 TAPstack device with FOUR Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 50/50, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK8L100G-M55 TAPstack device with SIX (8) Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 50/50, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK1L100G-M73 TAPstack device with One Link Passive fiber TAP supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 70/30, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK2L100G-M73 TAPstack device with TWO Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 70/30, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK4L100G-M73 TAPstack device with FOUR Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 70/30, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-TPSTCK8L100G-M73 TAPstack device with SIX (8) Links Passive fiber TAPs supports Multimode MTP to MTP 40G/50G/100G SR, Split ratio of 70/30, Slim 1/3U of 19" Rack height Net2XMTP/Mon1XMTP per link, requires MTP Y Cable (PN# EN-YMTP8F-OM4-3M)
EN-YMTP8F-OM4-3M 1x MTP 8 fibers Female to 2x MTP 4 fibers Female, OM4,Polarity B, Breakout length,0.5m. 3m.
TAPstack DUO: Dual Output LC TAP for LC Duplex links (other splits ratios available 50/25/25 or 40/30/30)
EN-TPSTCKD1L25G-M522 TAPstack DUO device with One Network Link and  2XTAP outputs per device: Multi Mode OM4 LC-LC 1x3 850 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, 1G/10G/25G Net4XLC/Mon4XLC per link
EN-TPSTCKD2L25G-M522 TAPstack DUO device with TWO Network Link and 4XTAP outputs per device: Multi Mode OM4 LC-LC 1x3 850 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, 1G/10G/25G  Net4XLC/Mon4XLC per link
EN-TPSTCKD4L25G-M522 TAPstack DUO device with FOUR Network Link  and 8XTAP outputs per device: Multi Mode OM4 LC-LC 1x3 850 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, 1G/10G/25G Net4XLC/Mon4XLC per link
EN-TPSTCKD6L25G-M522 TAPstack DUO device with  SIX Network Link and 12XTAP outputs per device: Multi Mode OM4 LC-LC 1x3 850 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, 1G/10G/25G Net4XLC/Mon4XLC per link
EN-TPSTCKD1L100G-S522 TAPstack DUO device with One Network Link and  2XTAP outputs per device: Single mode LC-LC 1x3 1310/1550 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, Net4XLC/Mon4XLC per link, 1G/10G/25G/40G/50G/100G
EN-TPSTCKD2L100G-S522 TAPstack DUO device with TWO Network Link and 4XTAP outputs per device: Single mode LC-LC 1x3 1310/1550 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, Net4XLC/Mon4XLC per link, 1G/10G/25G/40G/50G/100G
EN-TPSTCKD4L100G-S522 TAPstack DUO device with FOUR Network Link and 8XTAP outputs per device: Single mode LC-LC 1x3 1310/1550 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, Net4XLC/Mon4XLC per link, 1G/10G/25G/40G/50G/100G
EN-TPSTCKD6L100G-S522 TAPstack DUO device with  SIX Network Link and 12XTAP outputs per device: Single mode LC-LC 1x3 1310/1550 fiber coupler, Split Ratio: 50/25/25, Slim 1/3U of 19" Rack height, Net4XLC/Mon4XLC per link, 1G/10G/25G/40G/50G/100G
