Migrating to 400G? Choosing the Right Option (Part 5)
2022 Dec 17th
Inter-DC Connectivity optionsHere are the most common 400G optics modules used for
inter-DC connectivity.Optics Type: 400G-LR4
Description: Up to 10km over 1x SM fiber pair, using
four 100G PAM4 optical signals muxed on the fiber pair.
Fiber Type & fiber connector: Single-mode fiber,
Duplex LC connector
Use Case: For DCI applications for up to 10km.Optics Type:
400G-LR8
Description: Up to 10km over 1x SM fiber pair, using eight 50G PAM4
optical signals muxed on the fiber pair.
Fibe
read more
Migrating to 400G? Choosing the Right Option (Part 4)
Posted by Admin on 2022 Dec 17th
Between Leaf & Spine and Spine
& DCI connectivity optionsOptics Type: 400G-FR4
Description: Up to 2km over 1 SM fiber pair, using four
100G PAM4 optical signals muxed on the fiber pair. LC connector is used.
Fiber Type & fiber connector: Single-mode fiber,
Duplex LC connector
Use Case: Usually used between leaf, spine & DCI
within data centers, or across data centers for up to 2km useOptics Type: 400G-2FR4Description: Up to 2km over 2 SM fiber pairs, each
fiber pair carry
read more
Migrating to 400G? Choosing the Right Option (Part 3)
Posted by Admin on 2022 Dec 17th
Between ToR & Leaf Connectivity
OptionsOptics Type: 400G-AOC
Description: Up to 30m over multiple MM fiber pairs.
AOCs provide a complete solution, that includes two optics modules connected
using multiple fiber pairs. They come in different fiber lengths to cater to
different customer requirements.
Fiber Type & fiber connector: Usually MM fiber
Use Case: It is a cost-effective optical connectivity
option for short reach (up to 30m).1-400G QSFP-DD to 400G QSFP-DD, 400GE/200GE/HDR
read more
Migrating to 400G? Choosing the Right Option (Part 2)
Posted by Admin on 2022 Dec 17th
400G ToR to Server/storage Connectivity
optionsOptics Type: 400G-Direct Attach Cables (DAC) Description: QSFP-DD (Double-Density) passive copper cable assemblies provide 8 data transmission channels at speeds up to 25Gbps/lane NRZ and 50Gbps/lane PAM4. It enables 200G/400G in an application, with lengths 0.5-2 meters.. Fiber Type & fiber connector: Usually high-speed copper pairs Use Case: It is a cost-effective within-rack connectivity option for short reach (up to 3m).1- 40
read more
Migrating to 400G? Choosing the Right Option
Posted by Admin on 2022 Dec 16th
Migrating to 400G? Choosing the Right OptionAs
customers deploy 400G connectivity, they are transitioning from 25/100G
connectivity to 100/400G connectivity for the different tiers of the network. Before
making a decision, you should carefully consider your technical needs and
budget with these parameters in mind:
Reach:
the distance you need to transmit dataPower
ConsumptionFlexibility
– bending ratio. This is particularly important in tight spacesCost
Let us
read more
